SWITCH-MODE
RECTIFIERS
Software List
CPU Software available for DC & DCR rectifiers
| Software | Comm. Protocol | Description |
|---|---|---|
| Q63DCREV | CRS-ASCII DC | Standard firmware for DC & DCR rectifiers. |
| Q63DCPDP | Profibus DP | |
| Q63DCDVD | DeviceNet | |
| Q63MB_DC | Modbus | |
| Q63MBDCA | Analog card | |
| Q63DCPFN | Profinet - Modbus TCP | |
| Q63DCETH | EthernetIP - Modbus TCP | |
| Q63MULTW | - | Firmware installed on rectifiers in multitower configuration. |
| Software | Comm. Protocol | Description |
|---|---|---|
| Q63PFAST | CRS-ASCII (all others communication protocols available on request) | Standard firmware for fast pulsed rectifiers. Generates patterns made of up to six different steps. Minimum pulse duration is 1ms with 0,1ms increment. |
| Q63PSLOW | CRS-ASCII (all others communication protocols available on request) | Standard firmware for slow pulsed rectifiers. Generates patterns made of up to six different steps. Minimum pulse duration is 3ms with 0,1ms increment. If needed two rectifiers can operate in parallel via RS232 with different amplitudes for every step. |
| Q63PPPCB | CRS-ASCII (all others communication protocols available on request) | Special firmware for PCB applications. It can generate patterns made of two steps. Minimum pulse duration is 1ms with 0,1ms increment. If needed two rectifiers can operate in parallel with different amplitudes for every step. |
| Q63CRPFB | CRS-ASCII (all others communication protocols available on request) | Special firmware for decorative chrome application. This firmware allow the generation of a special waveform mixed with DC current and pulsed current to increase both deposit thickness and quality. This firmware requires either a remote control (REM) or a connection with a PC to operate. |
Contact our technical center for detailed documentation
