SWITCH-MODE
RECTIFIERS
PDF Q100
PDF Q300
PDF Q500
| Configuration | Weight | |
Air | Water | |
| 01 (mini) | 25 kg | 25 kg |
| Height | 154 mm | |
| Configuration | Weight | |
Air | Water | |
| 01-1 | 45 kg | 49 kg |
| Height | 369 mm | |
| Configuration | Weight | |
Air | Water | |
| 02-2 | 69 kg | - |
| Height | 501 mm | |
| Configuration | Weight | |
Air | Water | |
| 03-3 | 89 kg | - |
| Height | 633 mm | |
| Configuration | Weight | |
Air | Water | |
| 02-i1 | 79 kg | 86 kg |
| Height | 551 mm | |
| Configuration | Weight | |
Air | Water | |
| 03-1i1 | 99 kg | 110 kg |
| 03-Ri1 | 102 kg | 112 kg |
| Height | 683 mm | |
| Configuration | Weight | |
Air | Water | |
| 04-1i2 | 119 kg | 134 kg |
| 04-Ri2 | 122 kg | 136 kg |
| Height | 815 mm | |
| Configuration | Weight | |
Air | Water | |
| 05-1i1i1 | 143 kg | 160 kg |
| 05-2i2 | 139 kg | 158 kg |
| 05-1iRi1 | 146 kg | 162 kg |
| 05-1Ri2 | 142 kg | 160 kg |
| Height | 947 mm | |
| Configuration | Weight | |
Air | Water | |
| 06-2Ri2 | 162 kg | 184 kg |
| 06-1i2i1 | 163 kg | 184 kg |
| 06-2i3 | 159 kg | 182 kg |
| 06-1iRi2 | 166 kg | 186 kg |
| Height | 1079 mm | |
| Configuration | Weight | |
Air | Water | |
| 07-1i3i1 | 183 kg | 208 kg |
| 07-1iRRi2 | 189 kg | 212 kg |
| Height | 1211 mm | |
| Configuration | Weight | |
Air | Water | |
| 08-2i2i2 | 203 kg | 232 kg |
| 08-2i1Ri2 | 206 kg | 234 kg |
| 08-2iRRi2 | 209 kg | 236 kg |
| Height | 1343 mm | |
| Configuration | Weight | |
Air | Water | |
| 09-2i3i2 | 223 kg | 256 kg |
| 09-2iR1Ri2 | 229 kg | 260 kg |
| Height | 1475 mm | |
| Configuration | Weight | |
Air | Water | |
| 10-2i4i2 | 243 kg | 280 kg |
| 10-2i1RR1i2 | 249 kg | 284 kg |
| 10-2i1RRRi3 | 252 kg | 286 kg |
| Height | 1607 mm | |
| Configuration | Weight | |
Air | Water | |
| 11-2i2i2i2 | 267 kg | 306 kg |
| 11-3i3i3 | 287 kg | 304 kg |
| 11-3iRRRi3 | 293 kg | 310 kg |
| Height | 1739 mm | |
